Roll-Line Mistral Figure/Dance/Jam Skate Plates

0 Rating

$530.00

The Roll-Line Mistral (formerly named Navigator) is the pre-professional skate plate for high level skaters and serious competitors that want the most a skate can deliver!

Plate Size

Truck Axle Size

Cushions

Toe Stop

Back to: Plates

Description
Reviews

Roll-Line Mistral Figure/Dance/Jam Skate Plates

Suitable for: a professional use that ensures high performance.

The Roll-Line Mistral (formerly named Navigator) is the Pre Professional Skate Frame for the high level Skaters and serious competitors that want the most a skate can deliver, but are not quite ready for the Energy or Matrix.

Technical Specifications:
• A CNC machined frame forged from a solid bar of Avional Aluminum Alloy. (Avional is one of the Strongest and Lightest Aluminum Alloys available, just under the Ergal, and offers a very good coiled-spring response.)
• 7mm axels in the strongest steel available, with Optional 8mm axles available
• Adjustable pivot pins

• Roll-Line Click Action Adjustment System provides accurate and consistent Action adjustments using the 04 series, 13mm base King Pins with Adjustment Click Nuts and Locking Screws
• Comes with the Roll-Line standard set of wrenches

Toe Stop Options:
• Six toe stop options available – Super Professional (Natural) Toe Stops metric thread toe stops are included OR Choose other Professional Roll-Line stoppers, Mini Dance Plugs, OR Derby stoppers, available in the Pull-Down menu

Cushion Options:
• Choose Standard (Factory Installed Urethane), OR upgrade to your Choice of rubber or urethane suspensions, in a specific hardness.

Choosing a Size:
• Plates are sized according to wheelbase measurement (from centre of front axle to centre of rear axle) from 120mm to 210mm. If you aren't sure, please ask for advice on selecting the right size for your needs!

Manufacturer's Recommended Plate Sizes:

Plate Size	EURO Size	US Mens Size	US Ladies Size	EDEA Boot Size	Overall Frame Length (Centimeters)	WheelBase (Centre Axle to Axle Centimeters)	WheelBase (Centre Axle to Axle Inches)
120	34-34.5	J2.5-3	J3-3.5	225-230	20.9	12.0	4-11/16"
130	35-36	J3.5-4.5	4-5	235-240	21.9	13.0	5-1/8"
140	37-37.5	5-5.5	5.5-6	245-250	22.8	14.0	5-1/2"
150	38-39	6-7	6.5-7.5	255-260	24.0	15.0	5-7/8"
160	40-40.5	7.5-8	8-8.5	265-270	24.9	16.0	6-5/16"
170	41-42.5	8.5-9.5	9-10	275-285	25.9	17.0	6-11/16"
180	43-44	10-11	10.5-11.5	290-295	26.9	18.0	7-1/8"
190	45-47	11.5-13	12-13.5	300-310	27.9	19.0	7-1/2"
200	48	14	14.5	310-315	28.9	20.0	7-7/8"
210	49	15	15.5	315-320	29.9	21.0	8-1/4"
